80,000L Stainless Steel Palm Oil Tank
80,000L stainless steel palm oil tank is a sophisticated, custom-engineered vessel designed for reliability and efficiency. Its core features—food-grade stainless steel construction, an integrated heating system, agitation, and insulation—are all critical for handling the unique physical characteristics of palm oil in an industrial setting.
Product details
80,000L Stainless Steel Palm Oil Tank
80,000L Stainless Steel Palm Oil Tank is a significant piece of industrial equipment used for storage and processing, typically in mills, refineries, or bulk handling facilities.
Specification for 80,000L stainless steel palm oil tank as follows:
1.Sanitary Stainless steel 304, inside for the tank will be pickling and passivation and welding line will be polished;
2.Effective capacity:80m3;
3.Cylinder shape;
4.The thickness for bottom base is 5mm and the thickness of cylinder is 4mm and conical top is 4mm;
5.The size for the tank:diameter for 4500mm and height for 6000mm;
6.Centric top with 500mm top manway, EPDM;
7.1.5″Sample valve;
8.Discharge with butterfly valve and DN80mm;
9.3″Drain outlet;
10.Fully welded cladding;
11.Side oval manway, the size for the oval manway is 530mmx430mm, EPDM;
12.Breather pipe DN100mm;
13.The tanks without jacket and without insulation;
14.Liquid level gauge;
15.CIP spray ball;
16.Bimetallic thermometer;
17.The tank without leg, it is plinth mounted on the floor .
